              Wattage based Electric Tube Expansion Machine

              Wattage based Electric Tube Expansion Machine
              Wattage based Electric Tube Expansion Machine
              Send Inquiry
              Product Code : TCW-09-230
              Brand Name : BHARTIYA
              Price And Quantity
              • Minimum Order Quantity
              • 2
              • Unit of Measure
              • Piece/Pieces
              • Price Range
              • 145000.00 - 165000.00 INR
              • Price
              • RS. 1,45,000 TO RS. 1,65,000 INR
              Product Description

              Wattage based Electric Tube Expansion Machine

              • Fully Solid State Design - no moving parts - no wear and tear - no noise - consequently long life.
              • Uses the latest micro-controller chip for control functions.
              • Uses one main circuit board for easy maintenance.
              • Accurately calibrated digital torque setting with a resolution of 1 watt makes torque settings accurate and can be easily reproduced for identical results.
              • Connected drive is automatically recognized & indicated by means of LED on the torque controller.
              • Soft start has been provided for all drives, which reduces starting currents in the drive. As a result, life of carbon brushes & drive increases.
              • Torque setting arranged in four different ranges to suit four different drives. Appropriate wattage range is automatically selected for the connected drive, hence drives can not be abused or overused.
              • Actual drive wattage (torque) is displayed. Set wattage (torque), drive current and line voltage can be seen be Press of a button.
              • Adjustable reverse time from (1 sec to 100 secs.)
              • Trip time adjustable from (0.1 sec to 10 secs.)
              • Pause time (time interval between cycles) adjustable from ( 1 sec to 100 secs.)
              • Manual reverse by push button, in case of emergency.
              • Drive Speed adjustable in reverse rotation.
              • Hand (trigger) mode or foot switch mode, both are available.
              • Expansions can be carried out either in single cycle mode or auto repeat mode.
              • MCB has been provided to protect the drives against over current by short circuits..
              • Plug in type PCBs reduce down time to minimum during trouble shooting.
              • LED indicators provided for forward, reverse & trip conditions of drive.
              • Superior SCR technology has been incorporated ratherthan trics. SCRS have much better voltage, current dv/dt ratings  than triacs. This leads to greater reliability & the power circuit becomes almost failsafe.
              • All the spares inside the panel viz : PCBs, Transformers, CT, Relays DPM etc. Can be replaced by use of only a screw driver.
              • PC/Printer compatible.

              Model No.

              Voltage Single Phase 50/60 Hz

              Weight (kg)

              TCW-09-110

              100 V

              11.0

              TCW-09-230

              230 V

              11.0

              Trade Information
              • FOB Port
              • JNPT PORT
              • Delivery Time
              • 1 WEEK
              • Sample Policy
              • Within a certain price range free samples are available
              • Packaging Details
              • CORRUGATED BOX FOR AIR / COURIER MODE OR WOODEN BOX FOR SEA / ROAD TRANSPORTATION
              • Main Export Market(s)
              • Africa, Middle East, Western Europe, South America, Central America, Australia, Asia
              • Main Domestic Market
              • All India
              • Certifications
              • ISO-9001:2015
