              Portable Choked Tube Cleaners

              Portable Choked Tube Cleaners
              Portable Choked Tube Cleaners
              Send Inquiry
              Product Code : BC-750
              Brand Name : BHARTIYA
              Price And Quantity
              • Minimum Order Quantity
              • 2
              • Unit of Measure
              • Piece/Pieces
              • Price Range
              • 110000.00 - 135000.00 INR
              • Price
              • RS. 1,10,000 TO RS. 1,35,000 INR
              Product Specifications
              • Stirring Speed
              • 1000 RPM
              • Weight
              • 4.0 Kilograms (kg)
              Product Description

              Backed by our diligent employees and rich industrial experience, we have managed to become one of the leading manufacturers and suppliers of Portable Choked Tube Cleaners. Our professionals make use of premium quality components and the latest innovative techniques to make these cleaners. It consists of different parts including a drive shaft, coupling, threaded connections, air trigger, and starter drill (which is optional). Owing to its sturdy design, excellent functionality, and long lasting service life, these cleaners are highly appreciated by our clients. Prior to dispatch, these Portable Choked Tube Cleaners are duly checked on well-defined quality parameters to ensure full customer satisfaction.

              •  Portable pneumatic tube cleaners used hollow air craft quality shaft of different diameters s per        tube I.D. to be cleaned which can be coupled together to form length of the tube to be cleaned.     Water flows through the hollow tube & flushes out deposits that are loosened by the cleaning tools attached to hollow shaft. Tools used for cleaning are carbide drills, for severly clogged tubes, brushes for light deposits & buffing tools for final polishing. The rotation of air motor & the water flow are controlled independently

              Model No..

              Motor Power

              Tube ID

              Speed RPM

              Air Supply

              Water Supply

              Weight

              Hp

              kW

              Inch

              mm

              Min.

              Max.

              Min.

              Max.

              Ibs.

              kg.

              BC-20

              0.6

              0.45

              3/16-1

              4.8-25.4

              700

              60psi@16cfm

              90psi@16cfm

              30psi

              100psi

              5.72

              2.6

              BC-750

              1.2

              0.90

              7/8-2

              22.2-51.0

              1000

              90psi@20cfm

              90psi@40cfm

              30psi

              100psi

              6.60

              4.0



              •      Model BC-20 is generally used for oil coolers, small heat exchanger and condensers. 
              •      Model BC-750 is generally used for large diameter tubes of process equipment condensers and        heat exchangers



              Trade Information
              • FOB Port
              • JNPT PORT
              • Payment Terms
              • Telegraphic Transfer (T/T), Cash in Advance (CID), Cash Advance (CA), Cash on Delivery (COD)
              • Delivery Time
              • 1 WEEK
              • Sample Policy
              • Within a certain price range free samples are available
              • Packaging Details
              • CORRUGATED BOX FOR AIR / COURIER MODE OR WOODEN BOX FOR SEA / ROAD TRANSPORTATION
              • Main Domestic Market
              • All India
              • Certifications
              • ISO-9001:2015
