Portable Choked Tube Cleaners

Send Inquiry

Product Code : BC-750

Brand Name : BHARTIYA

Price And Quantity

Minimum Order Quantity
2
Unit of Measure
Piece/Pieces

Price
RS. 1,10,000 TO RS. 1,35,000 INR
Price Range
110000.00 - 135000.00 INR

Product Specifications

Stirring Speed
1000 RPM
Weight
4.0 Kilograms (kg)

Product Description

Backed by our diligent employees and rich industrial experience, we have managed to become one of the leading manufacturers and suppliers of Portable Choked Tube Cleaners. Our professionals make use of premium quality components and the latest innovative techniques to make these cleaners. It consists of different parts including a drive shaft, coupling, threaded connections, air trigger, and starter drill (which is optional). Owing to its sturdy design, excellent functionality, and long lasting service life, these cleaners are highly appreciated by our clients. Prior to dispatch, these Portable Choked Tube Cleaners are duly checked on well-defined quality parameters to ensure full customer satisfaction.

Portable pneumatic tube cleaners used hollow air craft quality shaft of different diameters s per tube I.D. to be cleaned which can be coupled together to form length of the tube to be cleaned. Water flows through the hollow tube & flushes out deposits that are loosened by the cleaning tools attached to hollow shaft. Tools used for cleaning are carbide drills, for severly clogged tubes, brushes for light deposits & buffing tools for final polishing. The rotation of air motor & the water flow are controlled independently

Model No..	Motor Power		Tube ID		Speed RPM	Air Supply		Water Supply		Weight
Model No..	Hp	kW	Inch	mm	Speed RPM	Min.	Max.	Min.	Max.	Ibs.	kg.
BC-20	0.6	0.45	3/16-1	4.8-25.4	700	60psi@16cfm	90psi@16cfm	30psi	100psi	5.72	2.6
BC-750	1.2	0.90	7/8-2	22.2-51.0	1000	90psi@20cfm	90psi@40cfm	30psi	100psi	6.60	4.0

Model BC-20 is generally used for oil coolers, small heat exchanger and condensers.
Model BC-750 is generally used for large diameter tubes of process equipment condensers and heat exchangers
